| 性能Performance | 1 | 额定载重量rated load | 5000kg |
| 2 | 整机重量overall weight | 17500kg | |
| 3 | 额定斗容量rated bucket capacity | 3.2 m3 | |
| 4 | 最大牵引力maximum tractive force | 152KN | |
| 5 | 最大崛起力maximum breakout force | ≥170KN | |
| 6 | 最大爬坡能力maximum grade ability | 30℃ | |
| 7 | 最大卸载高度maximum dump height | 3150mm | |
| 8 | 最大卸载距离maximum dump reach | 1250mm | |
| 9 | 整机外形尺寸overall dimension (L×W×H) | 8225×3016×3515mm | |
| 10 | 最小转弯半径minimum turning radius | 6640mm | |
| 发动机Engine | 11 | 型号model | 潍柴 Weichai WD10G220E21 |
| 12 | 型式type | 直列\水冷\干缸套\直喷 lnline water cooling dry cylinder injection |
|
| 13 | 气缸数-缸径×行程No. of cylinder-bore/stroke | 6－126×130mm | |
| 14 | 额定功率rated power | 162kw | |
| 15 | 最大扭矩maximum torque | 860N.m | |
| 16 | 最低燃油消耗率min fuel-consume ratio | ≤215g/kw.h | |
| 传动系统 Transmission system |
17 | 变矩器型式torque converter | ZL50 |
| 18 | 变速箱型式 gearbox mode | 行星式planetary | |
| 19 | 档位数gear shift | 前进档2个，倒退档1个 2forward shift 1reverse shift |
|
| 20 | 最高车速 maximum speed | 38km/h | |
| 驱动桥Drive axles | 21 | 主减型式：main reducing spiral |
螺旋伞齿轮一级减速 bevel gear grade 1reduction |
| 22 | 轮边减速型式decelerating mode | 一级行星减速 planetary reduction,grade 1 |
|
| 23 | 轴距 wheel base (mm) | 3340mm | |
| 24 | 轮距 wheel tread | 2250mm | |
| 25 | 最小离地间隙minimum ground clearance | 460mm | |
| 液压系统 Hydraulic system |
26 | 系统工作压力system working pressure | 18Mpa |
| 27 | 动臂提升时间 boom lifting time | 5.95±0.2s | |
| 28 | 三项和 total time | 10.95±0.5s | |
| 29 | 油箱容量 fuel tank capacity | 300L | |
| 30 | 铲斗自动放平功能 function of leveling automatically |
有 yes | |
| 制动系统 Brake system |
31 | 行车制动 service brake | 气顶油钳盘式四轮制动 air over hydraulic disc brake on 4 wheels |
| 32 | 驻车制动 parking brake | 手动钳盘式制动 manual parking brake | |
| 轮胎 Tyre |
33 | 规格type specification | 23.5-25 |
| 34 | 前轮气压 front tyre pressure | 0.4Mpa | |
| 35 | 后轮气压 rear tyre pressure | 0.35Mpa |
