| 性能Performance | 1 | 额定载重量 rated loading | 3000kg | |
| 2 | 整机重量 overall weight | 10200kg | ||
| 3 | 额定斗容量 rated bucket capacity | 1.8m3 | ||
| 4 | 最大牵引力 maximum tractive force | 97KN | ||
| 5 | 最大崛起力 maximum breakout force | 127KN | ||
| 6 | 最大爬坡能力 maximum grade ability | 30℃ | ||
| 7 | 最大卸载高度 maximum dump height | 3100mm | ||
| 8 | 最大卸载距离 maximum dump reach | 1006mm | ||
| 9 | 整机外形尺寸 overall dimension (L×W×H) | 6890×2400×3070mm | 标配 | |
| 3.4米 | ||||
| 7820*2560*3280mm | 3.6米 | |||
| 10 | 最小转弯半径 minimum turning radius | 5250mm | ||
| 发动机Engine | 11 | 型号model | WEICHAI WP6G125E22 | |
| 12 | 型式type | 立式直列、水冷、四冲程 lnline water cooled, four stroke |
||
| 13 | 气缸数-缸径×行程No. of cylinder-bore/stroke | 6—108×125mm | ||
| 14 | 额定功率 rated power | 92kw | ||
| 15 | 最大扭矩 maximum torque | 515N.m | ||
| 16 | 最低燃油消耗率 min fuel-consume ratio | ≤210g/kw.h | ||
| 传动系统 Transmission system |
17 | 变矩器型式 torque converter | YJ315—x | |
| 18 | 变速箱型式 gearbox mode | 定轴常啮合式 Power shift normally engaged straight gear |
||
| 19 | 档位数 gear shift | 前进档四个，倒退档二个 4forward shift 2 back shift |
||
| 20 | 最高车速 maximum speed | 40km/h | ||
| 驱动桥Drive axles | 21 | 主传动型式： main reducing mode | 螺旋伞齿轮一级减速式 Bevel gear grade lreduction |
|
| 22 | 轮边减速型式 decelerating mode | 一级行星减速Bevel gear grade lreduction | ||
| 23 | 轴距 wheel base (mm) | 2850mm | ||
| 24 | 轮距 wheel tread | 1800mm | ||
| 25 | 最小离地间隙 ground clearance | 400mm | ||
| 液压系统 Hydraulic system |
26 | 系统工作压力 system working pressure | 16.5MPa | |
| 27 | 动臂提升时间 boom lifting time | 4.83s | ||
| 28 | 三项和 total time | 9.15s±0.5s | ||
| 29 | 油箱容量 fuel tank capacity | 156L | ||
| 30 | 铲斗自动放平功能 function of leveling automatically |
有 yes | ||
| 制动系统 Brake system |
31 | 行车制动 service brake | 气顶油钳盘式四轮制动 air assist disc brake on 4 wheels |
|
| 32 | 驻车制动 parking brake | 手动钳盘式制动Manual disk brake | ||
| 轮胎 Tyre |
33 | 规格 type specification | 17.5-25 | |
| 34 | 前轮气压 front tyre pressure | 0.4Mpa | ||
| 35 | 后轮气压 rear tyre pressure | 0.35Mpa | ||
