Chassis Model |
ZZ3317N3847A |
|
Production Year |
used one |
|
Cabin |
HW76 cab, with one sleeper and two seats, air conditioner, |
|
Engine |
Engine model: WD615.47, Euro 2, 375HP/ 371hp |
|
Transmission |
HW19710, 10F & 2R |
|
Steering |
Hydraulic steering with power assitance |
|
Front Axle |
HF7, 1x7000 KGS Steering with doubleT-cross section beam |
|
Rear Axle |
HC16, 1x16000 KGS Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles. Ratio:4.42 |
|
Propeller Shaft |
Double universal joint propeller shaft with gear-shaped coupling flange |
|
Chassis |
Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members Front suspension:10 semi-elliptic leaf springs, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer |
|
Brake |
Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake |
|
Electrics |
Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light |
|
Tyres |
12.00R20 or 12R22.5 TIRES |
|
Fuel Tank |
400L |
